XMC-MA4

Form Factor: PMC/XMC
Category: Avionics Data Bus
Supplier: Alta Data Technologies (ADT)
Application(s): Airborne

Key Features

  • 1-5 Dual Redundant 1553/1553B Channels
  • 8 ARINC Channels: 4 Shared RX/TX & 4 RX
  • Ideal for Advanced Test or Embedded Applications
  • Commercial, Extended Temp/Rugged/Conduction Cooled
  • **Signal Capture on First Channels - Standard**
  • P4/P6 Rear Panel I/O & XMC 2.0 Connectors Optional
  • 512 KByte, 32-bit RAM per 1553/ARINC Device
  • Up to 2 ARINC 717 RX and TX Channels
  • Avionics and RS-485 Discretes
  • Full 1553 and ARINC Controls Like Other Alta Cards.
  • Dual and Full Function 1553 Channels.
  • Programmable ARINC Bit Rate (500-200K), Bit Encoding, Bits Per Word, Start/Stop and Parity
  • Dual Temperature Sensors
  • Digital Signal Generator - Fully Test Bit Encoding
Download: XMC-MA4.pdf
For more information, please click here.
